24V COB LED Neon Rope Light, 16.4ft IP67 Waterproof Silicone Strip, True Dotless Seamless Glow, CRI 90+ Warm White 3000K, Dimmable Glare-Free Tape for Cabinet, Outdoor

Description

24V COB LED strip  led Neon Rope Light, 16.4ft IP67 Waterproof Silicone Strip, True Dotless Seamless Glow, CRI 90+ Warm White 3000K, Dimmable Glare-Free Tape for Cabinet, Outdoor (Copy) (3000K/4000K/5000K/6500K) | 12V/24V DC

This high-density 3mm COB LED strip packs 384 LEDs per meter – eliminating visible dots and dark spots for buttery-smooth, professional-grade illumination. Utilizing advanced COB (Chip-on-Board) technology, micro-LEDs are encapsulated under a uniform phosphor layer, creating a continuous “neon-like” glow perfect for demanding applications.

Choose your ideal fixed color temperature during purchase:

3000K Warm White: Cozy ambiance (homes, restaurants)

4000K Neutral White: Balanced clarity (offices, retail)

5000K Cool White: Energy-enhancing focus (workshops, task lighting)

6500K Daylight: True color evaluation (galleries, studios)

With RA90+ color rendering (CRI >90), it reveals textures and hues with exceptional accuracy. UL Listed certification guarantees electrical safety compliance. The flexible circuit board bends smoothly around curves (min. 120° radius), while dual-voltage options (12V/24V) ensure broad compatibility.



Technical Specifications

Parameter	Specification
LED Configuration	COB Chip-on-Board (SMD-Free Design)
LED Density	384 LEDs/meter (Ultra-High Intensity)
Color Temperature (CCT)	3000K (Warm White) • 4000K (Neutral White) • 5000K (Cool White) • 6500K (Daylight White)
Color Rendering Index	RA90+ (CRI ≥90) – Ideal for color-critical applications
Voltage Options	DC12V Low Voltage • DC24V High Efficiency (Select model at purchase)
Power Consumption	12V: 14.4W/m ±5% • 24V: 28.8W/m ±5%
Luminous Flux	12V: 1,700 lm/m • 24V: 3,400 lm/m
PCB Material	2oz Copper Flexible FPC (3mm width)
Bending Radius	Min. 120° curvature
Cutting Units	Every 50mm (20 segments/m) with solder pads
IP Rating	IP20 Non-Waterproof (Indoor Dry Locations Only)
Working Temperature	-20°C to +45°C
Lifespan	50,000 hours (L70 @ Ta=25°C)
Certifications	UL Listed • CE • RoHS • FCC Compliant



---

💡 Unmatched Performance Features

✅ Zero Hotspot Illumination: Advanced COB LED strip lights packaging technology ensures <5% luminance deviation across the entire strip.
✅ True Color Rendition: RA90+ high CRI LED chips reveal authentic textures (R9>50) for retail displays, art galleries, and makeup studios.
✅ Enhanced Thermal Management: 2oz thick-copper PCB + phosphor silicone encapsulation reduces thermal resistance (θ<8°C/W).
✅ Flicker-Free Operation: Compatible with TRIAC/0-10V/PWM dimmers (flicker rate <1% @ 1kHz).
✅ Robust Connectivity: Pre-tinned solder pads support solderless connectors for rapid installation.

---

🏭 Professional-Grade Applications

• Architectural Lighting: Cove ceilings • Alcove lighting • Stair risers • Wall grazing • Recessed profiles

• Commercial Spaces: Retail display case lighting • Museum exhibit lighting • Jewelry cabinet illumination • Task lighting

• Residential Use: Kitchen under-cabinet lighting • Shelving accents • Wardrobe lighting • Furniture integrated lighting

• Specialized Environments: Photography light boxes • Plant grow light supplementation • Medical lighting • Art restoration

---

⚠️ Critical Installation Guidelines

1. Voltage Compliance: Strictly use UL Class 2 power supply matching voltage (12V/24V) with 20% power headroom.

2. Heat Dissipation: Mandatory aluminum channel installation for runs >1 meter (thermal pad adhesive recommended).

3. Maximum Run Lengths:

   • 24V: 5 meters w/single-end power • 10m w/dual-end feed

   • 12V: 2 meters w/single-end power • 5m w/dual-end feed

4. Cutting Protocol: Cut only at marked copper pads (every 50mm) using precision cutters.

5. Environmental Limits:

   • Avoid humid/damp locations (bathrooms, saunas)

   • Not rated for outdoor/weather-exposed installations
